CDM-40
Clip Nozzle Mounter

Fischbach CDM-40: Cartridge accessorizing with clip nozzle in a fully automatic operating cycle.

Features

  • Processes all kinds of plastic, aluminium or cardboard cartridges.

  • Useable as individual machine or part of a filling and packing line.

  • Cartridge accessorizing with clip nozzle in a fully automatic operating cycle.

  • The compact modular design enables the machine to be optimally adapted to customers individual packaging requirements, while taking up a minimum of space..

  • Trouble-free operation due to the latest process control.

  • Superior safety devices in compliance with the European CE Standard.

Technical Data

Output:

35 cartridges per minute

Type of Nozzles:

All standard clip nozzles

Type of Cartridges:

All standard cartridges

Height adjustment:

Mechanical or pneumatic

Voltage:

220 V, 50/60 Hz

Control Voltage:

24 V (internal)

Required ampere:

5 bar (75 psi)

Capacity of Clip Nozzle Magazine:

Approximately 300 clip nozzles

Weight:

300 kg

Control:

PLC

Air Consumption:

120 NL per Minute
