Fi-CL
Semi Automatic Cartridge Case Packer

Fischbach Cartridge Case Packer Fi – CL: Up t o 50 cartridges per minute accessorized and packed.

Features

  • Packages all kinds of plastic, aluminium or cardboard cartridges in one or two -piece version.

  • The compact modular design enables the machine to be optimally adapted to customers individual packaging requirements, while taking up a minimum of space.

  • DA packaging performance rate of 50 cartridges per minute with only one operator makes the Fi-CL the ideal supplement to any filling line.

  • Cartridge accessorized with clip nozzles completely integrated in one automatic operating cycle.

  • Program- controlled buffer magazine for 35 cartridges guarantees uninterrupted operation.

  • Well designed system for easily adjusted case formats; change of format accomplished without tools within less than three minutes.

  • Trouble-free operation due to latest process control and operation Interface.

  • Superior safety devices in compliance with European CE -Standard.

Technical Data

Output:

Up to 50 cartridges per minute (depending on box format)

Types of cartridges:

All standard cartridges

Packaging formats:

2×4, 2×5, 2×6, 3×4, 3×5, 3×6, 4×4, 4×5, 4×6, 5×4, 5×5, 5×6 cartridges per carton

Nozzle Accessorizing:

Automatic clip nozzle station (rate: 50 nozzles per minute)

Sealing of carton:

Externally – optional

Cartridge Buffer:

Standard capacity 35 cartridges

Weight:

600 kg

Current:

300 W (800 W with clip nozzle station)

Fuses:

6 ampere

Control:

Siemens PLC

Air Pressure:

6 bar minimum (90 psi.)

Air Consumption:

120 NL per minute (210 NL with clip nozzle station)
